How to Connect the Half Fold OBD2 Male Connector for GPS and Diagnostic Equipment


With the development of automotive technology, on board diagnostic systems (OBD) have become standard equipment for vehicles. The OBD2 male connector, as an important component of the OBD system, is widely used in GPS equipment and diagnostic equipment. This article will focus on the connection method of the half folded OBD2 male connector used for GPS and diagnostic equipment.


The connection method between the half folded OBD2 male connector and GPS equipment and diagnostic equipment is as follows:

Connect to GPS device: Insert the OBD2 female head of the GPS device into the 16 pin interface of the half folded OBD2 male connector, and then power the GPS device through the vehicle battery. The GPS device obtains the position information of the vehicle through the semi folding OBD2 male connector, achieving the vehicle positioning function.

Connecting to diagnostic equipment: Insert the OBD2 female head of the diagnostic equipment into the 16 pin interface of the half folded OBD2 male connector, and then power the diagnostic equipment through the vehicle battery. The diagnostic equipment obtains vehicle fault codes, operating data, and other information through a half folded OBD2 male connector, achieving vehicle fault diagnosis function.
